Introduction

1.1 Overview of Web Applications and Evolution of Web Architecture

World Wide Web (WWW)

World Wide Web (WWW), commonly known as the Web, is an information system enabling information to be shared over the Internet through simplified ways meant to appeal to users beyond IT specialists and hobbyists, as well as documents and other web resources to be accessed over the Internet according to specific rules, the Hypertext Transfer Protocol (HTTP).

What are Web Applications?

• Web applications are software programs that run on web servers and are accessed through web browsers over a network (typically the internet).
• Unlike traditional desktop applications, they don't require installation on the user's device.

Key Characteristics:

• Accessible from any device with a browser
• Centralized data storage and processing
• Automatic updates without user intervention
• Platform-independent operation


Evolution of Web or Rise of the World Wide Web

Web 1.0 (1990s - Early 2000s) - Static Web

• Read-only content
• Static HTML pages
• Limited interactivity
• One-way information flow from server to client
• Examples: Early corporate websites, online brochures (like newspaper with text and images)

Web 2.0 (Mid 2000s - 2010s) - Dynamic & Social Web

• User-generated content
• Rich user interfaces with AJAX
• Social networking and collaboration
• Two-way communication
• Corps monetizing your data
• Examples: Facebook, YouTube, Gmail

Web 3.0 (2010s - Present) - Semantic & Intelligent Web

• Artificial intelligence integration
• Semantic web technologies (web pages is structured and tagged in such a way that it can be read directly by computers)
• Users monetize their data
• Personalized experiences
• Machine learning and data analytics
• Decentralized applications (emerging)
• Examples: Voice assistants, recommendation systems, blockchain apps

Modern Web Applications - Current Trends

• Single Page Applications (SPAs)
• Progressive Web Apps (PWAs)
  • Features—like offline access, push notifications, and installability—that make it behave like a native mobile or desktop app.
• Microservices architecture
• Cloud-native applications taking full advantage of cloud computing's scalability and flexibility. (Google Colab, Google Docs, Figma)
• Real-time collaborative tools
• API-first design

---

Evolution of Web Architecture

• Monolithic Architecture:

  • The entire application (UI, business logic, data access) is built as a single, unified code base.
  • Easy to develop initially, simple to deploy (one file), easier debugging.
  • Hard to scale (must scale the whole app, not just bottlenecks),
  • A single bug can crash the whole system.
  • Example: Wordpress CMS

• Microservices:

  • Breaking the application into small, independent services that communicate via APIs (REST or gRPC). Each service can have its own database and technology stack.
  • Highly scalable, fault-tolerant (if one service fails, the app survives)
  • Enables independent teams to work on different features.
  • High complexity in DevOps, monitoring, and inter-service communication.
  • Example: Netflix, Amazon

• Event-Driven Architecture (EDA):

  • Services do not call each other directly (coupling). Instead, they emit "events" (e.g., "Order Placed") to a message broker (like Kafka or RabbitMQ), and other services listen and react.
  • Extreme decoupling, real-time responsiveness, high throughput.
  • Hard to trace the flow of logic; requires complex infrastructure.
  • Example: LinkedIn, Netflix, Amazon

• Serverless (FaaS):

  • Developers write individual functions (e.g., AWS Lambda) triggered by events. The cloud provider manages the servers entirely.
  • Zero server management, pay-only-for-execution.
  • Cold start problem (to boot up containers), vendor lock-in, distributed complexity
  • Example: Netflix, Amazon


Summary Table

---

The Request/Response Procedure

Basic Request/Response Procedure

At its most basic level, the request/response process consists of a web browser or other client asking the web server to send it a web page and the server sending back the page. The browser then takes care of displaying or rendering the page.

The steps in the request and response sequence are as follows:

1. You enter http://server.com into your browser’s address bar.
2. Your browser looks up the Internet Protocol (IP) address for server.com.
3. Your browser issues a request for the home page at server.com.
4. The request crosses the internet and arrives at the server.com web server.
5. The web server, having received the request, looks for the web page on its disk.
6. The web server retrieves the page and returns it to the browser.
7. Your browser displays the web page.

For an average web page, this process also takes place once for each object within the page: a graphic, an embedded video or Flash file, and even a CSS template.

Dynamic Request/Response Procedure

Dynamic web pages work by using PHP to request data from a MySQL database based on what you click. MySQL sends back the needed information, and PHP turns it into HTML, which your browser displays.

The steps are as follows:

1. You enter http://server.com into your browser’s address bar.
2. Your browser looks up the IP address for server.com.
3. Your browser issues a request to that address for the web server’s home page.
4. The request crosses the internet and arrives at the server.com web server.
5. The web server, having received the request, fetches the home page from its hard disk.
6. With the home page now in memory, the web server notices that it is a file incor‐ porating PHP scripting and passes the page to the PHP interpreter.
7. The PHP interpreter executes the PHP code.
8. Some of the PHP contains SQL statements, which the PHP interpreter now passes to the MySQL database engine.
9. The MySQL database returns the results of the statements to the PHP interpreter.
10. The PHP interpreter returns the results of the executed PHP code, along with the results from the MySQL database, to the web server.
11. The web server returns the page to the requesting client, which displays it.


1.2 Client-Server Architecture, HTTP, HTTPS, URLs, DNS, web browsers

Client-server architecture is a distributed computing model where tasks are divided between service providers (servers) and service requesters (clients).

Components:

Client (Frontend):

• User interface and presentation layer
• Sends requests to server
• Processes and displays responses
• Examples: Web browsers, mobile apps

Server (Backend):

• Processes client requests
• Manages business logic
• Handles data storage and retrieval
• Sends responses back to clients
• Examples: Web servers, database servers


Client-server architectures can be categorized into different tiers:

Single-tier Architecture(Monolithic Architecture):

• In a single-tier architecture, the entire application runs on a single machine or server.
• The user interface, application logic, and data storage are all combined into a single unit.
• This architecture is typically used for small-scale applications with limited complexity.

Two-tier Architecture:

• In a two-tier architecture, the application is divided into two main tiers: client and server.
• The client tier is responsible for the user interface and user interactions.
• The server tier handles the application logic, data processing, and storage.
• Communication between the client and server occurs directly.

Multi-tier Architecture:

• This architecture divides the application into three or more tiers, each responsible for specific functionality.
• Common tiers include the presentation tier (client interface), application tier (business logic), and data tier (data storage and retrieval).
• Each additional tier represents a distinct set of responsibilities or services.
• Additional tiers can include caching layers, load balancers, message queues, microservices, etc.
• This architecture allows for better scalability, flexibility, and modularity, but also increases complexity.

Advantages of Client-Server Architecture

• Centralized management simplifies maintenance and security.
• Scalability allows for easy addition of clients and servers.
• Flexibility enables independent development and updating of clients and servers.
• Enhanced security with centralized control and authentication.
• Data recovery and backup process is easier.

Disadvantages of Client-Server Architecture

• Single point of failure can disrupt services if the server goes down.
• Network congestion can occur with high demand on the server.
• Complexity in design and maintenance of multi-tier systems.
• Potential cost increase for server infrastructure and maintenance.

---

HTTP (HyperText Transfer Protocol)

What is HTTP?

• The HTTP protocol, or Hypertext Transfer Protocol, is a fundamental protocol used for communication on the World Wide Web.
• Defines how messages are formatted and transmitted between web browsers and servers.


Key Features

• Stateless Protocol: Each request is independent
• Request-Response Model: Client requests, server responds
• Text-Based: Human-readable format
• Port: Default port 80


HTTP Request

1. Request Line: An HTTP request starts with a request line, which includes the following:

• Method: This indicates the action to be performed on the resource. Common methods include GET (retrieve a resource), POST (submit data to the server), PUT (update a resource), DELETE (remove a resource), and others.
• Request URL: The URL of the resource being requested.
• HTTP Version: The version of the HTTP protocol being used.

2. Request Headers: Following the request line are headers, which provide additional information about the request. This can include details about the client’s browser, the types of responses that the client will accept, cookies, and more.

3. Blank Line: A blank line indicates the end of the headers section.

4. Request Body (Optional): Not all requests have a body. Bodies are typically included in POST or PUT requests, where you’re sending data to the server (like form inputs or file uploads). The body contains the data being sent.

HTTP Response

An HTTP response is what a server sends back to the client after receiving and processing an HTTP request. Here’s a breakdown of the components of an HTTP response:

1. Status Line: This is the first line of the response and includes:

• HTTP Version: Indicates the HTTP protocol version used (e.g., HTTP/1.1).
• Status Code: A three-digit number that indicates the outcome of the request. Common status codes include 200 (OK, request succeeded), 404 (Not Found, the resource can’t be found), 500 (Internal Server Error), etc.
• Status Text: A brief, human-readable explanation of the status code (e.g., OK, Not Found, Internal Server Error).

2. Response Headers: These are key-value pairs providing additional information about the response. They can include details such as the server type, content type, content length, caching policies, set cookies, and other metadata.

3. Blank Line: A blank line signifies the end of the header section.

4. Response Body: This part of the response contains the actual data or resource that the client requested. For example, it could be an HTML file, JSON data, an image, etc. In some cases, particularly when the response indicates an error (like a 404), the body might contain a message explaining the error.

• Date: The date and time the response was generated.
• Server: Information about the web server software (e.g., Apache/1.3.29).
• Last-Modified: The date and time the requested resource was last changed.
• ETag: An entity tag, a unique identifier for a specific version of a resource.
• Accept-Ranges: Indicates if the server supports partial requests. The server supports range requests, using byte-offsets as the unit. Support Resumable download for large files.
• Content-Length: The size of the message body in bytes (e.g., 35).
• Connection: How the client should handle the connection after the transaction (e.g., close).
• Content-Type: The media type of the resource in the body (e.g., text/html).

HTTP Methods (Verbs)

Head:

• A web cache can use a HEAD request with conditional headers (If-Modified-Since or If-None-Match) to ask the origin server if a cached resource is still fresh without requiring the content to be sent if it hasn't changed.
• Checking File Size Before Download and confirm download with user
• Link testing


HTTP Status Codes

1xx - Informational:

• 100 Continue
  • The 100 Continue response indicates that the server has received the initial part of the request (the headers) and is ready for the client to proceed with sending the request body (the payload).
  • The client first sends only the request headers and includes a special header: Expect: 100-continue. This is the client asking, "Before I send this huge file, are the headers acceptable?"
• 101 Switching Protocols
  • The most common use of the 101 status code is when establishing a WebSocket connection for real-time, bidirectional communication (like chat applications or live feeds).
  • The client sends an HTTP request (usually a GET) and includes the Upgrade header and the Connection: Upgrade header, specifying the desired new protocol (e.g., Upgrade: websocket).

2xx - Success:

• 200 OK
• 201 Created
• 204 No Content

3xx - Redirection:

• 301 Moved Permanently
• 302 Found (Temporary Redirect)
  • A temporary redirect is ideal for short-lived content, such as directing traffic from a permanent URL (e.g., /sales) to a seasonal landing page (e.g., /holiday-sale-2025) for a few weeks.
• 304 Not Modified (caching status)
  • It means the resource requested by the client has not been modified since the version specified by the client in its request headers (like If-Modified-Since or If-None-Match).

4xx - Client Errors:

• 400 Bad Request (invalid user data)
• 401 Unauthorized (not authenticated at all)
• 403 Forbidden (authenticated but not like admin user)
• 404 Not Found
• 429 Too Many Requests

5xx - Server Errors:

• 500 Internal Server Error
  • It is the server's way of saying, "Something went wrong, and I don't know exactly what."
  • Common Causes:
    • Application Crashes
    • web server lacks the necessary file permissions to run scripts or access databases.
• 502 Bad Gateway
  • This error often occurs in architectures with multiple layers, such as:
    • A web server (like Nginx or Apache) that acts as a reverse proxy receives a bad or incomplete response from the application server (where the code actually runs).
    • A CDN (Content Delivery Network) receives an error from the origin server.
• 503 Service Unavailable
  • The server is temporarily unable to handle the request due to temporary overloading or scheduled maintenance.
  • The response often includes a Retry-After header, indicating how long the service will be unavailable (e.g., Retry-After: 3600 for one hour).

---

HTTPS (HTTP Secure)

What is HTTPS?

HTTPS is the secure version of HTTP, using encryption to protect data transmission between client and server.

Key Features

• Encryption: Data is encrypted in transit
• Authentication: Verifies server identity using SSL certificates
• Data Integrity: Prevents data tampering
• Port: Default port 443


Benefits

• Protects sensitive data (passwords, credit cards)
• Builds user trust
• SEO benefits (Google ranks HTTPS higher)
• Required for modern web features (geolocation, camera access)

---

URLs (Uniform Resource Locators)

Structure of a URL

Copy
https://www.example.com:443/path/to/myfile.html?key1=val1&key2=val2#SomewhereInTheDocument

Protocol: https://
Subdomain: www
Domain: example
Top-level domain (TLD): .com
Port: :443
Path: /path/to/myfile.html
Query String: ?key1=val1&key2=val2
Fragment: #SomewhereInTheDocument

Components Explained

Protocol (Scheme):

• Defines how to access the resource
• Examples: http, https, ftp, smtp

Domain Name:

• subdomain + domain + TLD
• Human-readable address
• Maps to IP address via DNS
• Can include subdomains (www, blog, api)

Port:

• Optional, defaults to 80 (HTTP) or 443 (HTTPS)
• Specifies which service on the server to connect to

Path:

• Location of specific resource on server
• Organized hierarchically with forward slashes

Query String:

• Starts with "?"
• Key-value pairs separated by "&"
• Example: ?id=123&category=books

Fragment (Hash):

• Starts with "#"
• Points to specific section within a page
• Not sent to server


URL Encoding

Special characters must be encoded:

• Space: %20 or +
• &: %26
• =: %3D
• #: %23

---

DNS (Domain Name System)

What is DNS?

DNS is the internet's phone book, translating human-readable domain names into IP addresses that computers use to communicate.

How DNS Works

1. User enters URL: www.example.com in browser
2. Browser checks cache: Looks for recently resolved IP
3. Recursive resolver: ISP's DNS server receives request
4. Root nameserver: Directs to TLD nameserver (.com)
5. TLD nameserver: Directs to authoritative nameserver
6. Authoritative nameserver: Returns IP address
7. Browser connects: Uses IP to reach website


DNS Record Types

SPF (Sender Policy Framework)

• Specifies which services (like Resend) or IP addresses are authorized to send emails on behalf of your domain.
• Prevents spammers from sending fake emails using your domain.

DKIM (DomainKeys Identified Mail)

• Publishes public keys used to verify email signatures. Used by receiver (gmail server) to verify message signed by (resend).
• Improves email deliverability and prevents tampering.

Domain verification

• Google Site Verification is the process of proving to Google that you own a domain or website so you can access Google services related to that domain, such as:
  • Google Analytics
  • AdSense, etc
  • Also used by Facebook, Email providers, etc

DNS Hierarchy

Copy
Root (.)
  └── Top-Level Domain (.com, .org, .net)
      └── Second-Level Domain (example.com)
          └── Subdomain (www.example.com)

.com.np is also at TLD level, Country Code TLD i.e. ccTLD

DNS Caching

• Browser cache: Short-term local storage
• OS cache: System-level DNS cache
• ISP cache: Service provider's DNS servers
• TTL (Time To Live): Determines cache duration

---

Search Engines

What is a Search Engine?

A search engine is a software system designed to carry out web searches. They search the World Wide Web in a systematic way for particular information specified in a textual web search query.

How Search Engines Work

1. Crawling:

• Search engines use bots (spiders/crawlers) to browse the web.
• They follow links from one page to another to discover new content.

1. Indexing:

• The discovered pages are analyzed and stored in a massive database (index).
• Content is categorized based on keywords, freshness, and relevance.

1. Ranking:

• When a user searches, the engine retrieves matching results.
• Algorithms rank these results based on relevance, authority, and user signals (SEO).

Popular Search Engines

• Google (Dominant market share)
• Bing (Microsoft)
• Yahoo
• DuckDuckGo (Privacy-focused)
• Baidu (China)
• Yandex (Russia)

---

Web Browsers

What is a Web Browser?

A web browser is a software application that retrieves, presents, and navigates information resources on the World Wide Web.

Popular Browsers

• Google Chrome
• Mozilla Firefox
• Safari
• Microsoft Edge
• Opera
• Brave


Browser Components

1. User Interface:

• Address bar
• Back/forward buttons
• Bookmarks
• Tabs and windows

2. Browser Engine:

• Acts as a bridge between the User Interface and the Rendering Engine.
• It handles inputs from the UI (like clicking "Back" or typing a URL) and commands the Rendering Engine to display the correct content.

3. Rendering Engine:

• Displays requested content
• Parses HTML and CSS
• Examples: Blink (Chrome), Gecko (Firefox), WebKit (Safari)

4. Networking:

• Handles HTTP/HTTPS requests
• Manages cookies
• Implements caching

5. JavaScript Engine:

• Parses and executes JavaScript code
• Examples: V8 (Chrome), SpiderMonkey (Firefox)

6. Data Storage:

• Cookies
• LocalStorage
• SessionStorage
• IndexedDB
• Cache API


How Browsers Render Pages

• When a browser receives a web page, it first parses the HTML to create the DOM (Document Object Model), which represents the structure of the content.
• Simultaneously, it parses the CSS to build the CSSOM (CSS Object Model), defining the styles for each element.
• These two trees are then combined into a Render Tree, which contains only the visible elements.
• The browser then performs the Layout (or Reflow) step, calculating the exact position and size of each element on the screen.
• Finally, the browser Paints the pixels for each element onto the screen.
• If the page has complex visual effects (like overlapping elements or 3D transforms), it uses a Composite step to layer these painted parts together correctly for the final display.


Browser Features

Developer Tools:

• Inspect HTML/CSS
• Debug JavaScript
• Monitor network activity
• Analyze performance

Security Features:

• Same-origin policy
• HTTPS enforcement
• Pop-up blockers
• Phishing protection

Modern Capabilities:

• Progressive Web App support
• WebRTC for real-time communication
• WebAssembly for high-performance code
  • allowing high-performance languages (C++, Rust) to run in the browser for demanding apps like games or video editors.
• Geolocation API
• Notifications API

---

JavaScript and Client-Side Programming
